Prefabricated Carbon Steel Structure Industrial Plant Workshop Warehouse and Outdoor Hall/ Farmhouse Storage Solution
| Place of Origin | Hebei,China |
|---|---|
| Brand Name | BAODU |
| Certification | ISO9001,CE |
| Model Number | Steel Warehouse |
| Document | Baodu Company Profile.pdf |
| Minimum Order Quantity | Discussible |
| Price | Reasonable |
| Packaging Details | In general, for steel structure , we use the steel frame packing to keep goods not to be broken . For sandwich panel and color steel sheet, we use the plastic packing . If the clients need special packing will according to their requirements. |
| Delivery Time | 21days |
| Payment Terms | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Supply Ability | 10000 Square Meter/Square Meters per Month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Prefabricated Carbon Steel Structure Industrial Plant Workshop Warehouse And Outdoor Hall/ Farmhouse Storage Solution | Keyword | Steel Structure Building Warehouse |
|---|---|---|---|
| Structure Type | Long-span Grid Structure | Usage | Workshop Warehouse Construction Office |
| Drawing Design | SAP2000/AutoCAD /PKPM /3D3S/TEKLA | Secondary Structure | Purlin; Brace; Knee Brace Etc |
| Application | Apartment, Office Building, Poultry Houses, Garage Shed，warehouse，steel Structure Building | After-sale Service | Online Technical Support, Onsite Training |
| Design Style | Modern | Project Solution Capability | 3D Model Design, Total Solution For Projects |
| Highlight | prefab steel warehouse building,carbon steel industrial plant structure,outdoor farmhouse storage workshop |
||
You can tick the products you need and communicate with us in the message board.
Product Description
Prefabricated Carbon Steel Structure Industrial Plant Workshop Warehouse and Outdoor Hall/ Farmhouse Storage Solution
Product Attributes
| Attribute | Value |
|---|---|
| Product name | Prefabricated Carbon Steel Structure Industrial Plant Workshop Warehouse and Outdoor Hall/ Farmhouse Storage Solution |
| Keyword | Steel Structure Building Warehouse |
| Structure type | Long-span Grid Structure |
| Usage | Workshop Warehouse Construction Office |
| Drawing Design | SAP2000/AutoCAD /PKPM /3D3S/TEKLA |
| Secondary Structure | Purlin; Brace; Knee Brace etc |
| Application | Apartment, Office Building, poultry houses, garage shed，warehouse，steel structure building |
| After-sale Service | Online technical support, Onsite Training |
| Design Style | Modern |
| Project Solution Capability | 3D model design, total solution for projects |
Product Specifications
| Item | Description |
|---|---|
| Model | Single slope,double slope,multi slope.Single span,double-span,Multi-span Single floors, Double floors |
| Main steel grade | Q235B, Q345B |
| Column & Beam | Welded or Hot rolled H-section steel, constant cross-section or variable cross-section. H 160~2000*150~800*6/8/10*6/8/10/12mm. Two coats of primer and finish paint. |
| Wall & Roof | EPS,Fiber glass,Rockwool,PU sandwich panel 50/75/100mm, and corrugated steel sheet 0.5~0.8 mm |
| Wall & Roof purlin | C / Z channel steel, Hot dip galvanized.C80~C300, Z100~Z300 |
| Bracing | X or V type Steel round bar, Angle steel and tubes, painted or galvanized. |
| Strut | Steel round pipe and tube, and angle steel, painted. |
| Sag rod | Steel round bar, galvanized. |
| Eave Gutter | Galvanized / Stainless steel sheet |
| Downspout | UPVC pipe Diameter 110mm |
| Trim & Flashing | Bended color steel sheet |
| Door | Roll-up, Sliding, Lifting and Hinged door etc |
| Window | Plastic steel, Aluminum alloy window etc |
| Canopy | Color corrugated steel sheet, Sandwich panel |
| Skylight | Polycarbonate sheet 0.8/1.2mm |
| Roof ventilation | Monitor or natural ventilator |
| Bolt | Foundation anchor bolt 10.9S 8.8S, Commercial bolt 4.8S, Expansion bolt. |
| Accessories | Screw, Rivet, Foam closures, Sealant, Ventilator, etc |
Design Drawing
Design Parameters
| Parameter | Considerations |
|---|---|
| Live load on roof | KN/M² |
| Wind speed | KM/H |
| Snow load | KG/M² (If Applicable) |
| Earthquake load | If Applicable |
| Doors and Windows | Customizable styles |
| Crane Specifications | If required: span, lift height, capacity, wheel pressure |
Processing
Certifications
Support and Services
Our prefabricated steel structures come with comprehensive technical support and services to ensure project success. Our expert team provides:
- Installation guidance and detailed drawings
- Maintenance advice and troubleshooting support
- Dedicated customer service for complete satisfaction
- Technical consultation throughout your project
Packing and Shipping
All components are carefully packaged for secure transportation:
- Sturdy wrapping and crating for damage prevention
- Clear labeling for easy identification
- Reliable shipping partners for timely delivery
- Tracking information provided for all shipments
Why Choose Us
- We have a team of professional engineers, most of whom have an average of 20 years of experience in the steel structure design field. Our company has extensive experience in design, manufacture, installation and more. The work staff have excellent skills. Some of them have helped customers install warehouses around the world.
- We offer one stop service. Construction drawings, calculation sheets will be provided to help you get construction permits. Foundation design could be made for free if needed. We can create 3D drawings to show the view. Installation drawings will be provided and steel structure columns, beams will be numbered to assist with installation.
- We will send you spare bolts and panels in case of any damage during installation.
- Efficiency is our pursuit. Every inquiry and email will be replied to immediately. Every question will receive high attention.
- We possess more than 40 sets of large precise and domestically advanced processing equipment, including large gantry planing machines, automatic submerged arc welding machines, assembling machines, slitters, shot blasting machines and more.
- We provide detailed packing lists for every container when loading to make unloading easier.
- Form A, Form E, CE, GOST, etc certifications are available.
