Roof Heat / Fire Resistant Rockwool Acoustic Panel Lightweight Foam Insulated 75mm

Place of Origin Hebei,China
Brand Name BAODU
Certification CE
Model Number Rockwool Sandwich Panel
Minimum Order Quantity Discussible
Price Reasonable
Packaging Details In general, for steel structure , we use the steel frame packing to keep goods not to be broken . For sandwich panel and color steel sheet, we use the plastic packing . If the clients need special packing will according to their requirements.
Delivery Time 15days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 5000 Square Meters per Day

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Roof Heat & Fire Resistant Lightweight Foam Rockwool Insulated Sandwich Panel Application Wall Building Warehouse Roofing Wall And Roof
Soundproof Yes Thickness 50mm 75mm 80mm 100mm 125mm 150mm 200mm
Width 1000mm Advantage Superior Fireproof-insulation Fire Proof Light Weight&Easy To Install Fireproof Innovative Technology
Usage Construction Insulation Shop Outdoor Office Length Customized
Color RAL Color;Customized Word Rockwool Insulated Sandwich Panel
High Light

rockwool acoustic panel 75mm

,

fire resistant rockwool acoustic panel

,

rockwool sandwich panel 75mm

Leave a Message
Product Description

Roof Heat & Fire Resistant Lightweight Foam Rockwool Insulated Sandwich Panel

Product Description:

Rockwool Sandwich Board is a modern designed, thermal insulated building material. It is composed of two layers of pre-painted steel sheets and high-density rockwool as the core material, with PU sealant applied. The density of the rockwool is between 90-150kg/m3, and the thickness is available in 50mm, 75mm, 80mm, 100mm, 125mm, 150mm and 200mm. The product has passed CE certification. This type of Rockwool Sandwich Board is ideal for use in a wide range of building structures, providing a durable and energy-efficient solution.

Features:

  • Product Name: Rockwool Sandwich Panel
  • Advantage: Superior Fireproof-insulation, Fire Proof, Light Weight & Easy To Install, Fireproof, Innovative Technology
  • Width: 1000mm
  • Soundproof: Yes
  • Color: RAL Color;Customized
  • Density: 90-150kg/m3



Technical Parameters:

Technical parameters of BAODU new model fireproof sandwich panel
Allowable vertical load and thermal conductivity of BAODU new model fireproof rockwool roof sandwich panel (allowable deflection f≤L/200)
S(mm) W/m²K G(kg) P=KN/m2 0.60 0.80 1.00 1.20 1.50
50 0.75 15.53 L(m) 3.66 3.13 2.75 2.46 2.12
70 0.53 18.37 L(m) 4.90 4.22 3.73 3.35 2.91
100 0.41 21.21 L(m) 5.99 5.17 4.58 4.12 3.59
125 0.36 24.05 L(m) 6.91 5.96 5.28 4.79 4.14
150 0.31 26.88 L(m) 7.82 6.75 5.98 5.37 4.68
200 0.23 22.78 L(m) 9.65 8.33 7.38 6.62 5.77
Allowable vertical load and thermal conductivity of BAODU new model fireproof glasswool roof sandwich panel (allowable deflection f≤L/200)
S(mm) W/m²K G(kg) P=KN/m2 0.60 0.80 1.00 1.20 1.50
50 0.69 12.95 L(m) 3.74 3.23 2.86 2.57 2.23
70 0.47 14.50 L(m) 5.01 4.34 3.86 3.48 3.05
100 0.36 16.04 L(m) 6.21 5.32 4.73 4.28 3.75
125 0.34 17.06 L(m) 7.11 6.31 5.77 4.93 4.32
150 0.33 19.14 L(m) 8.00 6.94 6.18 5.58 4.89
200 0.30 22.78 L(m) 9.79 8.56 7.63 6.88 6.00

    Applications:



BAODU Rockwool Sandwich Panel is the perfect composite building material with excellent thermal insulation and fire resistant properties. It is made of two layers of high-quality structural steel and a non-combustible rockwool core. With its advanced design and modern style, it is widely used in both commercial and residential construction applications such as insulation, shop outdoor, office, etc. Manufactured in Hebei, China, it meets the European CE standards and comes with a discussible minimum order quantity of 300-500 square meters. Due to its reasonable pricing, it is highly cost-effective and can be delivered within 15 days. The payment terms are flexible and can be L/C, D/A, D/P, T/T, Western Union, MoneyGram. It has a supply ability of 5000 square meters per day and can be packed in steel frame or plastic according to customer requirements. Moreover, BAODU provides online technical support and onsite installation services for Rockwool Sandwich Panel.

   Customization:



Rockwool Sandwich Panel
  • Brand Name: BAODU
  • Model Number: Rockwool Sandwich Panel
  • Place of Origin: Hebei,China
  • Certification: CE
  • Minimum Order Quantity: Discussible
  • Price: Reasonable
  • Packaging Details: In general, for steel structure , we use the steel frame packing to keep goods not to be broken . For sandwich panel and color steel sheet, we use the plastic packing . If the clients need special packing will according to their requirements.
  • Delivery Time: 15days
  • Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability: 5000 Square Meters per Day
  • Heat-insulation: Yes
  • Length: Customized
  • After-sale Service: Online Technical Support, Onsite Installation
  • Usage: Construction Insulation Shop Outdoor Office
  • Design Style: Modern
  • Keywords: Rockwool Insulated Panels, Rockwool Sandwich Board, Rockwool Insulated Board

   Support and Services:



Technical Support and Service for Rockwool Sandwich Panel

At Rockwool, we are dedicated to providing our customers with the highest quality products and services. We offer comprehensive technical support and service for Rockwool Sandwich Panel products, including:

  • Expert advice on product selection and installation;
  • On-site training and technical assistance;
  • Technical literature and installation instructions;
  • Product warranty and after-sales service;
  • Troubleshooting and problem resolution.

Our experienced team of professionals are here to help you with all your Rockwool Sandwich Panel needs. Contact us today to learn more about our products and services.
