Roof Foam Sheet Polyurethane Sandwich Panel Customizable Moistureproof

  • Roof Foam Sheet Polyurethane Sandwich Panel Customizable Moistureproof
  • Roof Foam Sheet Polyurethane Sandwich Panel Customizable Moistureproof
Place of Origin Hebei,China
Brand Name BAODU
Certification CE
Model Number Polyurethane Sandwich Panel
Document Product Brochure PDF
Minimum Order Quantity Discussible
Price Reasonable
Packaging Details In general, for steel structure , we use the steel frame packing to keep goods not to be broken . For sandwich panel and color steel sheet, we use the plastic packing . If the clients need special packing will according to their requirements.
Delivery Time 15days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 5000 Square Meters per Day

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Roof Foam Sheet Customizable Polyurethane Sandwich Panel Sound Proofing Acoustic Panel Design Style Modern
Thickness 50mm-200mm,etc After-sale Service Online Technical Support
Color RAL Color;Customized Steel Thinckness 0.4mm-0.8mm
Heat Insulation Yes Moistureproof Yes
Highlight

customizable polyurethane sandwich panel

,

Moistureproof polyurethane sandwich panel

,

customizable pu sandwich panel
Leave a Message
Product Description

Roof Foam Sheet Customizable Polyurethane Sandwich Panel Sound Proofing Acoustic Panel

Product Description:

Our Polyurethane Sandwich Panel is a great choice for cost-effective and reliable building material. It is made of two layers of steel sheets with a polyurethane insulation core, which is weather-resistant and highly moistureproof. It is also great for heat insulation, and its reasonable price makes it an attractive choice for many projects. The width is 1000mm, allowing for easy installation and providing solid structural strength. Our Sandwich Panels Polyurethane and Pu insulation polyurethane sandwich panel are specially designed to provide superior insulation and strength, perfect for any Polyurethane Sandwich Wall Roof Panel. We have a wide range of sizes and designs for different applications, so you can find the perfect solution for your project.



Features:

  • Product Name: Polyurethane Sandwich Panel
  • Moistureproof: Yes
  • Material: Polyurethane
  • Color: RAL Color;Customized
  • After-sale Service: Online Technical Support
  • Length: Customizable According To Customer Needs


Technical Parameters:

Allowable vertical load and thermal performance of BAODU polyurethane sandwich wall
panel (allowable deflection f≤L/200)
S(mm) W/m2k G(kg) P=KN/m2 0.60 0.80 1.00 1.20 1.50
50 0.31 10.06 L(m) 3.52 3.04 2.69 2.42 2.11
75 0.21 11.06 L(m) 4.71 4.09 3.64 3.29 2.89
100 0.19 12.05 L(m) 5.76 5.02 4.47 4.05 3.56
120 0.16 12.84 L(m) 6.53 5.68 5.07 4.60 4.04
150 0.11 14.04 L(m) 7.56 6.58 5.87 5.32 4.68
Note:0.5mm outer steel sheet and 0.4mm inner steel
Allowable Span and Thermal Conductivity of BAODU Polyurethane Roof Sandwich
Panel(allowable deformation f≤L/240)
S(mm) W/m2k G(kg) P=KN/m2 0.60 0.80 1.00 1.20 1.50
30 0.32 9.32 L(m) 2.60 2.30 2.08 1.91 1.72
50 0.31 10.15 L(m) 3.59 3.17 2.85 2.61 2.33
75 0.21 11.18 L(m) 4.64 4.07 3.66 3.34 2.96
100 0.19 12.22 L(m) 5.57 4.88 4.38 3.99 3.53
120 0.16 13.05 L(m) 6.28 5.49 4.92 4.48 3.97
150 0.11 14.3 L(m) 7.30 6.39 5.73 5.22 4.62
Note:0.5mm outer steel sheet and 0.4mm inner steel


Applications:

Warehouse

Workshop

Farm building

Prefabricated house

Hangar

Cold storage

Support and Services:

Our Polyurethane Sandwich Panel comes with technical support and service. Our team of experts is available to help with installation and troubleshooting to ensure you get the most out of your purchase. We offer phone and online support, and can help guide you through any issues you may be having. We also offer extended warranties and maintenance services to keep your Polyurethane Sandwich Panel in top shape for years to come.
