Prefabricated Rockwool 100mm Sandwich Panel for Roof Building

Place of Origin Hebei,China
Brand Name BAODU
Certification CE
Model Number Rockwool Sandwich Panel
Minimum Order Quantity Discussible
Price Reasonable
Packaging Details In general, for steel structure , we use the steel frame packing to keep goods not to be broken . For sandwich panel and color steel sheet, we use the plastic packing . If the clients need special packing will according to their requirements.
Delivery Time 15days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 5000 Square Meters per Day

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Fire Proof Sound Proof Rockwool Sandwich Panel For Exterior Wall Roof Building With Waterproof Key Words Rockwool Sandwich Panel
Heat-insulation Yes Density 100kg/m3
Core Material Rockwool Board Design Style Modern
Usage Construction Insulation Shop Outdoor Office Width 1000mm
Waterproof Yes MOQ Reasonable
High Light

Prefabricated 100mm sandwich panel

,

Roof 100mm sandwich panel

,

Rockwool prefabricated sandwich panels

Leave a Message
Product Description

Fire Proof Sound Proof Rockwool Sandwich Panel For Exterior Wall Roof Building With Waterproof

Product Description:

Our Rockwool Sandwich Panel is a type of insulated panel that provides superior fireproof, heat-insulation and waterproof characteristics. It is constructed with two metal sheets that are connected by a core of rock wool material. The width of the Rockwool Sandwich Panel is 1000mm, and the color of the panel can be customized according to customer requirements. These insulated panels offer excellent soundproofing and fireproofing, making them an ideal choice for many applications. With PU edge, the Rockwool Sandwich Panel can be used in any environment, such as in warehouses and other industrial spaces. It is also easy to install, making it a cost-effective and convenient option.

Features:

High mechanical resistance

High level of thermal resistance

High level of acoustic resistance

High resistance to fire

Applications:

1.Industrial Facilities

2.Commercial Building

3.Social Construct

4.Power Plants

5.Agricultural objects

6.Sport halls

Technical Parameters:

Technical parameters of BAODU new model fireproof sandwich panel
Allowable vertical load and thermal conductivity of BAODU new model fireproof rockwool roof sandwich panel (allowable deflection f≤L/200)
S(mm) W/m²K G(kg) P=KN/m2 0.60 0.80 1.00 1.20 1.50
50 0.75 15.53 L(m) 3.66 3.13 2.75 2.46 2.12
70 0.53 18.37 L(m) 4.90 4.22 3.73 3.35 2.91
100 0.41 21.21 L(m) 5.99 5.17 4.58 4.12 3.59
125 0.36 24.05 L(m) 6.91 5.96 5.28 4.79 4.14
150 0.31 26.88 L(m) 7.82 6.75 5.98 5.37 4.68
200 0.23 22.78 L(m) 9.65 8.33 7.38 6.62 5.77
Allowable vertical load and thermal conductivity of BAODU new model fireproof glasswool roof sandwich panel (allowable deflection f≤L/200)
S(mm) W/m²K G(kg) P=KN/m2 0.60 0.80 1.00 1.20 1.50
50 0.69 12.95 L(m) 3.74 3.23 2.86 2.57 2.23
70 0.47 14.50 L(m) 5.01 4.34 3.86 3.48 3.05
100 0.36 16.04 L(m) 6.21 5.32 4.73 4.28 3.75
125 0.34 17.06 L(m) 7.11 6.31 5.77 4.93 4.32
150 0.33 19.14 L(m) 8.00 6.94 6.18 5.58 4.89
200 0.30 22.78 L(m) 9.79 8.56 7.63 6.88 6.00


Customization:

BAODU Rockwool Sandwich Panel is a cost-effective thermal and sound insulation solution that offers excellent performance. The panel is made of high-quality rockwool insulation material that provides superior thermal insulation and excellent sound absorption. The panel has a smooth surface and is easy to install. It can be used for both indoor and outdoor applications and is highly resistant to fire and moisture. BAODU Rockwool Sandwich Panel is the perfect choice for creating a comfortable and energy-efficient environment.

Support and Services:

Rockwool Sandwich Panel Technical Support and Service

We provide comprehensive technical support and service for Rockwool Sandwich Panel products. Our technical team is available to answer any questions or provide assistance with installation, repairs, or any other issues related to the product.

We will work with you to ensure that the product is properly installed and functioning optimally. We can provide training and advice on installation, maintenance, and safety precautions. We also offer on-site troubleshooting and repair services if needed.

We provide a wide range of services, including product demonstrations, installation and repair services, and warranties on all products. We are committed to providing the best customer service and technical support to ensure that your experience with our products is as seamless and successful as possible.

Packing and Shipping:

Rockwool Sandwich Panel Packaging and Shipping:

The Rockwool Sandwich Panel is usually packaged in plastic film first, and then packed in steel sheet. It is recommended to store the product in dry conditions and avoid direct exposure to the sun and rain.

The delivery of the Rockwool Sandwich Panel is usually done by sea or air transport. The packaging should be marked clearly, including product name, product specifications, quantity, weight, destination, etc. The delivery time will vary depending on the distance of the destination.

BAODU:

Baodu International Advanced Construction Material Co., Ltd was established in January 2010 with the office in Beijing and factory in Hebei, China. Baodu is a designer, manufacturer, supplier and exporter of industrial noise comprehensive treatment, steel structure, sandwich panel and prefab house. Baodu has an annual output of 6 million square meters of acoustic sandwich panels, 100000 tons of steel structures and 1 million square meters of floor decking sheet. The products are sold in more than 30 countries and regions around the world. Baodu has a professional design team with more than 10 years’ experience, including 5 senior engineers, 20 engineers, and 35 technicians. Baodu has several energy saving and environment protection intellectual property rights, construction and environment protection design qualification, CE certification and Russian GOST certification etc. Baodu participated in the military parade village project for the 60th anniversary of China and project of Beijing Daxing International Airport. Under the guidance of China's "one belt, one road" strategy, Baodu has also undertaken overseas projects such as the project of Thar,Pakistan coal fired power plant, Hasyan Dubai power plant and so on. Finally, welcome your coming to Baodu for a visit and cooperation!
