Industrial Flat Steel PUR Sandwich Panel 0.4mm-0.8mm Exterior interior wall
| Place of Origin | Hebei,China |
|---|---|
| Brand Name | BAODU |
| Certification | CE |
| Model Number | Polyurethane Sandwich Panel |
| Document | Product Brochure PDF |
| Minimum Order Quantity | 500square meters |
| Price | Reasonable |
| Packaging Details | In general, for steel structure , we use the steel frame packing to keep goods not to be broken . For sandwich panel and color steel sheet, we use the plastic packing . If the clients need special packing will according to their requirements. |
| Delivery Time | 15days |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 5000 Square Meters per Day |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Polyurethane Sandwich Panel Steel 0.4mm-0.8mm Thickness For Industrial Usage | Thickness | 50mm-200mm,etc |
|---|---|---|---|
| Surface | Customized | Material | Polyurethane |
| Color | RAL | Moistureproof | Yes |
| Width | 1000mm | Structure | Sandwich Panel |
| Application | Warehouse,Exterior Interior Wall,Building,Cold Storage,roof And Curtain Wall Insulation | ||
| Highlight | Industrial PUR Sandwich Panel,Flat PUR Sandwich Panel,Industrial flat sandwich panel |
||
Product Description
Polyurethane Sandwich Panel Steel 0.4mm-0.8mm Thickness for Industrial Usage
Product Description:
Polyurethane Sandwich Panel is a high-quality insulation material with excellent thermal insulation and soundproof performance. The panel is made of polyurethane foam and two layers of high strength metal plates, with a total thickness of 50mm-200mm and customized length. It is an ideal material for thermal insulation and sound insulation. The price of the product is reasonable and we provide online technical support for after-sale service. Pu insulation polyurethane sandwich panel offers excellent insulation properties, and it is the perfect solution for Sandwich Panels Polyurethane Foam.
Features:
- Strong sound insualtion
- Waterproof and moisture-proof
- Class A fire protection
- Heat preservation
Applications:
- Warehouse
- Workshop
- Farm building
- Prefabricated house
- Hangar
- Cold storage
Technical Parameters:
| Allowable vertical load and thermal performance of BAODU polyurethane sandwich wall panel (allowable deflection f≤L/200) |
||||||||
| S(mm) | W/m2k | G(kg) | P=KN/m2 | 0.60 | 0.80 | 1.00 | 1.20 | 1.50 |
| 50 | 0.31 | 10.06 | L(m) | 3.52 | 3.04 | 2.69 | 2.42 | 2.11 |
| 75 | 0.21 | 11.06 | L(m) | 4.71 | 4.09 | 3.64 | 3.29 | 2.89 |
| 100 | 0.19 | 12.05 | L(m) | 5.76 | 5.02 | 4.47 | 4.05 | 3.56 |
| 120 | 0.16 | 12.84 | L(m) | 6.53 | 5.68 | 5.07 | 4.60 | 4.04 |
| 150 | 0.11 | 14.04 | L(m) | 7.56 | 6.58 | 5.87 | 5.32 | 4.68 |
| Note:0.5mm outer steel sheet and 0.4mm inner steel | ||||||||
| Allowable Span and Thermal Conductivity of BAODU Polyurethane Roof Sandwich Panel(allowable deformation f≤L/240) |
||||||||
| S(mm) | W/m2k | G(kg) | P=KN/m2 | 0.60 | 0.80 | 1.00 | 1.20 | 1.50 |
| 30 | 0.32 | 9.32 | L(m) | 2.60 | 2.30 | 2.08 | 1.91 | 1.72 |
| 50 | 0.31 | 10.15 | L(m) | 3.59 | 3.17 | 2.85 | 2.61 | 2.33 |
| 75 | 0.21 | 11.18 | L(m) | 4.64 | 4.07 | 3.66 | 3.34 | 2.96 |
| 100 | 0.19 | 12.22 | L(m) | 5.57 | 4.88 | 4.38 | 3.99 | 3.53 |
| 120 | 0.16 | 13.05 | L(m) | 6.28 | 5.49 | 4.92 | 4.48 | 3.97 |
| 150 | 0.11 | 14.3 | L(m) | 7.30 | 6.39 | 5.73 | 5.22 | 4.62 |
| Note:0.5mm outer steel sheet and 0.4mm inner steel | ||||||||
Support and Services:
Polyurethane Sandwich Panel provides technical support and service, including installation guidance, product usage instructions, product troubleshooting and after-sales maintenance.
The installation guidance includes product structure, installation process and precautions. The product usage instructions mainly explain the product's operating environment and operating procedures. Troubleshooting services are provided to assist clients in resolving product-related problems. Our after-sales maintenance services include regular maintenance and maintenance services for damaged parts.
FAQ:
.Q1. What about your price?
A1. We have our own factory so that we can provide the best price for you
Q2.What is your advantages.
A2. As a high technology company in the construction material industry, we have our own professors team which has more than 10 people in Beijing related institution. And we also have the strict quality control in our production lines.
Q3. What is your payment term and delivery time?
A3. We accept the T/T or L/C. And the Ali trade assurance also be acceptable. As for the delivery time, we need make the production plan for each order. Usually , it will take 15- 30 days after we confirm the order.
